Zenmuse S1
Industry-grade large UAV spotlight payload featuring LEP laser white light technology. Delivers high brightness and long-range illumination with multiple lighting modes, designed for night operations in public safety, emergency rescue, and inspection scenarios.
Core Specifications
Product Name
Zenmuse S1
Weight
760±10 g
Size
Length: 125 mm, Width: 152 mm, Height: 171 mm
Rated Power
120 Watts (Matrice 400) 68 Watts (Matrice 300 RTK / Matrice 350 RTK)
Supported Models
Matrice 400 Matrice 350 RTK Matrice 300 RTK (requires DJI RC Plus)
Eye Safety Level
IEC 62471: Risk Group 1
Product Video Introduction
Video sourced from the official DJI product page for reference.Zenmuse S1appearance and core functionality
* The video is an official DJI product video for reference on product form and features; actual configuration and pricing are subject to inquiry results.
Full Specifications
| Product Name | Zenmuse S1 |
| Weight | 760±10 g |
| Size | Length: 125 mm, Width: 152 mm, Height: 171 mm |
| Rated Power | 120 W (Matrice 400) 68 W (Matrice 300 RTK / Matrice 350 RTK) |
| Supported Models | Matrice 400 Matrice 350 RTK Matrice 300 RTK (Requires DJI RC Plus) |
| Eye Safety Level | IEC 62471: Risk Group 1 |
| Hot casing | < 50°C (plastic housing) |
| Protection Rating | IP54 achieves an IP54 rating under IEC 60529 standards in controlled laboratory conditions. Protection ratings are not permanent; performance may degrade due to product wear. |
| Environmental Parameters · Operating Temperature | -20°C to 40°C |
| Environment Parameters · Storage Temperature | -20°C to 60°C |
| Gimbal Parameters · Stabilization System | 3 Axis (Pitch, Roll, Translation) |
| Gimbal Parameters · Angle Jitter | Hover: ±0.01° | Flight: ±0.02° |
| Pan/Tilt Parameters · Mounting Method | DJI SkyPort Quick-Release |
| Gimbal Parameters · Mechanical Angle Range | Pitch: -129° to +73°, Roll: ±55.8°, Translation: ±327°. Structural limits, not soft control limits. |
| Pan Parameters · Controllable Rotation Range | Pitch: -120° to +60°, Yaw: ±320° |
| Gimbal Parameters · Working Mode | Follow, Free, Center |
| Lighting Parameters · Max Center Illuminance | 40 lux @ 100 m (Matrice 400, Full Open Mode) 35 lux @ 100 m (Matrice 300 RTK / Matrice 350 RTK, Full Open Mode) This |
| Lighting Parameters · Low Beam Center Illuminance | 20 lux @ 100 m (Matrice 400, low beam) 13 lux @ 100 m (Matrice 300 RTK / Matrice 350 RTK, low beam) |
| Lighting Parameters · High Beam Center Illuminance | 30 lux @ 100 meters (high beam mode) |
| Lighting Parameters · Effective Illumination Angle | 15±1° (10% relative illuminance, low beam and full beam modes) 4±0.5° (10% relative illuminance, high beam mode) |
| Lighting Parameters · Typical Color Temperatures | Typical value 6500K (low beam) Typical value 7500K (high beam) This |
| Light Parameters · Dimming Mode | Simulate Dimming |
| Light Parameters · Effective Spotlight Range | 500 meters (full-open mode) This |
| Basic Features · Light Control | Switch, Brightness |
| Basic Features · Strobe Mode | 5 Hz strobe |
| Basic Features · Light Modes | Low Beam Mode, High Beam Mode, Full-On Mode |
| Basic Features · Key Mapping | Support mapping for power on/off, brightness adjustment, and lighting mode switching |
| Basic Features · PTZ Linkage | Supports linked control with other PTZ-type payloads |
| Key Features · Eye Protection | Automatically limit brightness to 40% when not airborne |
| Key Features · Load Protection | LED/LEP thermal protection, overcurrent protection, and power protection to prevent damage |
| Key Features · Centralized Control | When mounting two Zenmuse S1 units on the Matrice 400, both spotlights can be controlled simultaneously. |
| Key Features · Guangxin Smart Alignment | When mounted with the Zenmuse H30 series on the Matrice 400, Zenmuse S1 automatically adjusts the gimbal angle in dual-gimbal sync mode to optimize alignment between the spotlight's optical center and the camera. |
* Specifications are sourced from DJI's official product page; actual configurations may vary by factory. Prices are subject to inquiry.
Download Product Brochure
Below isZenmuse S1Product Brochure Preview: Click the button to generate and download a PDF version for internal review and selection archiving.
Huaying Technology Co., Ltd. · Product Brochure
Zenmuse S1
Load Series· Authorized DJI distributor supply
High-power spotlight payload for large-scale industrial drones, featuring LEP laser white light technology. Delivers high brightness and long-range illumination with multiple lighting modes, ideal for nighttime operations in public safety, emergency rescue, and inspection scenarios.
| Product Name | Zenmuse S1 |
| Weight | 760 ± 10 g |
| Size | Length: 125 mm, Width: 152 mm, Height: 171 mm |
| Rated Power | 120 Watts (Matrice 400) 68 Watts (Matrice 300 RTK / Matrice 350 RTK) |
| Supported Models | Matrice 400 Matrice 350 RTK Matrice 300 RTK (requires DJI RC Plus) |
| Eye Safety Level | IEC 62471: Risk Group 1 |
| Hot to the touch | < 50°C (plastic housing) |
| Protection Rating | IP54 achieves an IP54 rating under IEC 60529 standards in controlled laboratory conditions. Protection ratings are not permanent; performance may degrade due to product wear. |
| Environmental Parameters · Operating Temperature | -20°C to 40°C |
| Environment Parameters · Storage Temperature | -20°C to 60°C |
| Gimbal Parameters · Stabilization System | 3 Axis (Pitch, Roll, Translation) |
| Gimbal Parameters · Angle Jitter | Hover: ±0.01° Flight: ±0.02° |
| Pan-Tilt Parameters · Mounting Method | DJI SkyPort Quick-Release |
| Gimbal Parameters · Mechanical Angle Range | Pitch: -129° to +73°, Roll: ±55.8°, Translation: ±327°. Structural limits, not control soft limits. |
| Pan Tilt Parameters · Controllable Rotation Range | Pitch: -120° to +60° | Yaw: ±320° |
| Gimbal Parameters · Working Mode | Follow, Free, Center |
| Lighting Parameters · Max Center Illuminance | 40 lux @ 100 m (Matrice 400, Full Beam Mode) 35 lux @ 100 m (Matrice 300 RTK / Matrice 350 RTK, Full Beam Mode) This |
| Lighting Parameters · Low-Beam Center Illuminance | 20 lux @ 100 m (Matrice 400, Low Beam) 13 lux @ 100 m (Matrice 300 RTK / Matrice 350 RTK, Low Beam) |
| Lighting Parameters · High Beam Center Illuminance | 30 lux @ 100 m (high beam mode) |
| Lighting Parameters · Effective Illumination Angle | 15±1° (10% relative illuminance, low beam and full beam modes) 4±0.5° (10% relative illuminance, high beam mode) |
| Lighting Parameters · Typical Color Temperature | Typical value 650K (low beam) Typical value 750K (high beam) This |
| Light Parameters · Dimming Mode | Simulate Dimming |
| Light Parameters · Effective Spotlight Range | 500 meters (full-open mode) This |
| Basic Features · Lighting Control | Switch, Brightness Adjustment |
| Basic Features · Strobe Mode | 5 Hz strobe |
| Basic Features · Lighting Mode | Low Beam, High Beam, All-On Mode |
| Basic Features · Key Mapping | Support mapping for power on/off, brightness adjustment, and lighting mode switching |
| Basic Features · PTZ Linkage | Supports linked control with other PTZ-type payloads. |
| Key Features · Eye Protection | Automatically limits brightness to 40% when not airborne. |
| Key Features · Load Protection | LED/LEP thermal protection, overcurrent protection, and power protection to prevent damage |
| Key Features · Centralized Control | When two Zenmuse S1 units are mounted on the Matrice 400, both floodlights can be controlled simultaneously. |
| Key Features · Guangxin Intelligent Alignment | When mounted alongside the Zenmuse H30 series on the Matrice 400, the Zenmuse S1 automatically fine-tunes the gimbal angle in dual-gimbal linkage mode to optimize alignment between the spotlight's light center and the camera. |
