Huawei IdeaHub Board 3 Pro
SmartOffice: User-Friendly Interface
Equipped with a 4K soft-light display featuring physical blue light protection, it combines 1 6ms low-latency writing, P2P screen sharing, and a vast app ecosystem. Ideal for meeting rooms, open discussion areas, training centers, and more—perfect for lightweight digital workflows.
- Model
- IdeaHub Board 3 Pro
- Technical Specifications
- 10 group · 34 items
- Use Cases
- Meeting RoomOpen DiscussionTraining Room
- 4K Soft-Light Display: Protects Your Eyes for More Comfortable Meetings
- P2P Screen Casting – No Wi-Fi Required, One-Step Direct
- Cross-screen annotation. Write and save anytime.
- Dual OS: One-click Quick Switch
- 16ms ultra-low writing latency for a buttery-smooth pen feel
Technical Specifications
10 groups of 34 items, sourced from Huawei's official product pages and brochures
- Complete Unit
- 1 units
- Stylus
- 2 pcs
- Accessory cables
- 1 power cord
- Smart Screen Cast
- Optional (Type-C / Type-A)
- Ground-mounted bracket
- Optional
- Wall Mount Bracket
- Optional
- Resolution
- 4K
- Backlight Type
- D-LED
- Craftsmanship fit
- Zero Fit
- Color Gamut
- 85%NTSC
- Frequency domain
- 100Hz-20kHz
- Number of Speakers
- 4
- Maximum Power
- 30W
- Pickup Angle
- 180°
- Number of Microphones
- 6
- Pickup Distance
- 10m
- Dual Wi-Fi Module
- Wi-Fi5 + Wi-Fi6
- Frequency
- 2.4GHz + 5GHz
- NFC
- Support
- CPU
- 8 Core
- RAM
- 8GB
- Flash
- 64GB*
- Operating System
- HarmonyOS/Windows (OPS required)
- Meeting-ready
- Native meetings: Huawei Cloud Meeting SmartRooms, Huawei Cloud WeLink; Third-party meeting apps: Tencent Meeting Rooms, Feishu Rooms
- Meeting Effectiveness
- Native meetings: Huawei Cloud Meeting SmartRooms, Huawei Cloud WeLink: 1080P30fps video; Third-party meeting apps: Tencent Meeting Rooms: 1080P video, Feishu Meeting Rooms: 720P video
- Write latency
- 16ms
- Whiteboard Save Options
- Scan QR code / Email / Local / USB
- Smart Writing Recognition
- Support
- Touch Height
- 1.5mm
- pre-interface
- Type-C x 1; USB 3.0 x 2
- Side-mounted interface
- USB 2.0 x 2; USB 3.0 x 1; HDMI IN x 2; HDMI OUT x 1; COM port x 1; 3.5mm Line-out x 1; 3.5mm Line-in x 1; RJ45 x1 (10/100/1000M LAN); Type-B x 1
- Product Dimensions (mm)
- "65": 1484.5 x 91.6 x 892.5; "75": 1705.7 x 91.8 x 1016.9; "86": 1953.0 x 91.8 x 1157.0
- Package Dimensions (mm)
- "65": 1650 x 220 x 1050; "75": 1900 x 220 x 1170; "86": 2090 x 250 x 1300
- Weight (Net/Gross)
- 65": 35.2 kg; 42.7 kg; 75": 46.7 kg; 56.7 kg; 86": 61.6 kg; 73.1 kg
Product Brochures & Resources
IdeaHub Board 3 Pro Brochure - V25.1
This catalog page lists the features and specifications for this model. View online or print to save as a PDF.
InquireIdeaHub Board 3 Pro
Share your screen size, installation method, and preferred meeting platforms. We'll provide configuration recommendations, quotes, and delivery timelines.
- Direct from manufacturer; pricing available upon request.
- Assist with verifying OPS, stand, and projector选配 configurations.
- Parameters and brochures are subject to Huawei's official documentation.
